Model 1:HYJ-600 mechanical type

Max. Flange thickness:         20mm

Flange width：                    150-600mm

Web height：                      ≥150mm

Straightening speed:           5.7m/min

Motor power:                       9 Kw

H-beam material：             Q235A



Model 2:HYJ-800 mechanical type:

Flange max thickness：      40mm

Flange width：              200-800mm

Web beam min height：       160mm

Straightening speed：       ≈13 m/min

Machine power：             15.2Kw





Model 3:YTJ-60B hydraulic type



Flange max thickness:     60mm(Q345)

Flange width :            200-800 mm

Flange thickness:          ≤60mm

Web height:               ≥350mm

Motor Power:              29.5 kw

Max output torque:        43000N.m

Straightening speed:      6.5m/min

Oil pump output:          40ml/r

Max system pressure:      31.5Mpa

Normal working pressure:  27.5Mpa



Model 4:YTJ-80B hydraulic type

Flange max thickness:          80mm

Flange width :                 300-1000mm

Flange thickness:              ≤80mm

Web height:                    ≥500mm

Material：                     16Mn

Drive motor:                   22 kw

Max output torque:             43000N.m

Straightening speed:           6m/min

Oil pump drive motor:          22 kw

Oil pump output:               40ml/r

Max system pressure:           31.5Mpa

Normal working pressure:       27.5Mpa
